DXF135 36V 48V 250W electric bicycle hub motor E-bike Motor

36V 48V 250W Electric Bicycle Hub Motor E-bike Motor Rear Wheel Drive DXF135 Disc Brake System

This is a 250W 36V Brushless Hub Motor for E-bike. This monster Hub Motor is for Self-balancing Cars & Scooters.

The motor has the connection wires for the hall sensor and temperature controller making it more easy to control. One can use this Hub motor and Tire combo in Self-balancing Car, Electric Scooter, Skateboard, E-bike, ATV, Electric Roller, DIY Conversion Kit, E-Scooter, etc.

Specification:

• Model: DXF135
• Nominal Voltage (V): 36 V / 48 V
• Nominal Power (W): 250 W
• Wheel size (inch): 16-28 inch
• Nominal Speed ??(km / h): 25-28 km / h
• Gear ratio: 1: 4.4
• Weight (KG): 3.2
• Spoke: 36 hole spoke 12G / 13G
• Position: Rear
• Build: Gear
• Dropout / Open Size (mm): 135mm
• Magnet Poles (2 p): 10
• Type of brake: Disc brake
• Freewheel: 6 S-9 S
• Cabling Route: Center right
• Operating temperature (ºC): -20-45 ºC
• Efficiency (%): 78%
• Noise Grade (DB) <55
• IP Grade: IP65
• Salt Spray Test Standard (h) 96
• Surface Color: silver

Package Includes:

1 x  250W 36V 328 RPM Brushless Hub Motor for E-bike
