MJE13003 Power Switch Transistor NPN SMD SOT-252
- Product Category: Bipolar Transistors – BJT
- Mounting Style: SOT-252
- Package/Case: SOT-252
- Transistor Polarity: NPN
- Configuration: Single
- Collector- Emitter Voltage VCEO Max: 400 V
- Collector- Base Voltage VCBO: 100 V
- Emitter- Base Voltage VEBO: 5 V
- Collector-Emitter Saturation Voltage: 0.5 V
- Maximum DC Collector Current: 1.5 A
- Pd – Power Dissipation: 1.4 W
- Gain Bandwidth Product fT: 3 MHz
- Minimum Operating Temperature: – 65 C
- Maximum Operating Temperature: + 150 C
- Continuous Collector Current: 1.5 A
- DC Collector/Base Gain hFE Min: 8
- Product Type: BJTs – Bipolar Transistors
- Subcategory: Transistors
Availability:
Only 7 left in stock
₨ 60
Only 7 left in stock
These Power 2 A, 400 V NPN Bipolar Power Transistor is designed for high voltage power switching inductive circuits where fall time is critical. They are particularly suited for 115 and 220 V SWITCHMODE applications such as Switching Regulators, Inverters, Motor Controls, Solenoid/Relay drivers and Deflection circuits.
Features:
- Reverse Biased SOA with Inductive Loads @ TC = 100? C
- Inductive Switching Matrix 0.5 to 1.5 Amp, 25 and 100 ° C
tc @ 1 A, 100 ° C is 290 ns (Typ) - 700 V Blocking Capability
- SOA and Switching Applications Information.
- Pb-Free Package is Available
