3 to 8 line Decoder / Demultiplexer 74HC138
• Logic Type: decoder / demultiplexer
• No. output channels: 8
• Supply Voltage Range: 2V to 6V
• Package Type: DIP
• Pin number: 16
• Operating temperature range: -55 ° C to +125 ° C
• SVHC: No SVHC
• Device label: 74
• Device Marking: HD74HC138P
• Package Type: DIP
• Operating Temperature Min: -55 ° C
• highest working temperature: 125 ° C
• Supply Voltage: 6V
• Supply voltage: 6V
• The minimum supply voltage: 2V
• chip label: 74HC138
• Surface Mount Devices: through-hole mounting
• Output Current: 5.2mA
• logic chip function: Logic 4-to-16 Line Decoder / Demultiplexer
• logic chip series: HC
₨ 40
The 74HC138N is a 3 to 8-line decoder/demultiplexer with three enable inputs, E1, E2 and E3.
A High on E1 or E2, or Low on E3 forces the output into the High state. The demultiplexing function is performed by using the three input lines, A0 to A2, to select the output lines Y0 to Y7.
In many ways, this IC is a smaller version of 74HC154
