ICs Categories
ICs
Showing 1–48 of 92 resultsSorted by latest
-
Discrete Electronic Components, General ICs, ICs
LCR-T4 Diode Triode Capacitance Esr Meter Transistor Checking Tool
Discrete Electronic Components, General ICs, ICsLCR-T4 Diode Triode Capacitance Esr Meter Transistor Checking Tool
LCR-T4 ESR Meter is an all in one universal LCR Meter and NPN, PNP, FET, MOSFET, Transistor, Inductor, Resistor, Capacitor LED and Diode tester. This LCRT4 diode triode Capacitance best transistor tester automatic test the pin of a component, and display on the LCD.
SKU: 1908 -
Discrete Electronic Components, General ICs, ICs
CH341A USB Flash BIOS Tool USB Programmer EEPROM BIOS Flasher
Discrete Electronic Components, General ICs, ICsCH341A USB Flash BIOS Tool USB Programmer EEPROM BIOS Flasher
- Support most 24/25 series EEPROM BIOS chip, recognize 25 series chip automatically.
- The SOP8 clip enables in-circuit programming of EEPROM without disassembling the chip, making flashing the BIOS simpler and more efficient.
- Root online is available with USB to TTL port.
- Directly connecting MSI mainboard to flash is available with SPI pin which is corresponding to MSI JSP11 port.
- Downloading STC series software of singlechip is available.
SKU: 1907 -
Discrete Electronic Components, General ICs, ICs
74244 74LS244 /SN74LS244N / SN74LS244 3-State Output Octal Buffer or Line Driver IC
Discrete Electronic Components, General ICs, ICs74244 74LS244 /SN74LS244N / SN74LS244 3-State Output Octal Buffer or Line Driver IC
Applications
- The IC can be used for Noise Removing.
- It has wide use in Power meter and Power analyzers.
You can download this Datasheet for 74LS14 Hex Inverter Schmitt Trigger from the link given below:
SKU: 1683 -
Discrete Electronic Components, ICs, Logic Gates
74LS112 Dual JK Negative Edge Triggered Flip-Flop IC
Discrete Electronic Components, ICs, Logic Gates74LS112 Dual JK Negative Edge Triggered Flip-Flop IC
74LS76 comes with dual JK flip flops. JK flip flops are widely used in daily electronics devices by many methods but the basic operation of the JK flip flop is to store a bit. JK flip flop allows to store a bit and then allows it to use for further functions. in digital electronics circuits. JK flip flop is one of the popular flip flops due to its clock input, pre-set, and clear functionalities. The JK flip-flop changes its state under the clock pulse signal. The clock signal can be either a positive edge or a negative edge. The clock pulse gives multiple advantages to the flip flop. 74LS76 also has provided a feature to neglect or prevent invalid outputs.
SKU: 1523 -
Discrete Electronic Components, ICs, Logic Gates
74LS76 DUAL JK FLIP-FLOP IC
74LS76 comes with dual JK flip flops. JK flip flops are widely used in daily electronics devices by many methods but the basic operation of the JK flip flop is to store a bit. JK flip flop allows to store a bit and then allows it to use for further functions. in digital electronics circuits. JK flip flop is one of the popular flip flops due to its clock input, pre-set, and clear functionalities. The JK flip-flop changes its state under the clock pulse signal. The clock signal can be either a positive edge or a negative edge. The clock pulse gives multiple advantages to the flip flop. 74LS76 also has provided a feature to neglect or prevent invalid outputs.
SKU: 1587 -
Discrete Electronic Components, ICs, Logic Gates
74LS85 4-Bit Magnitude Comparator IC
What is a 4-bit Magnitude Comparator?
A 4-bit magnitude comparator compares two binary numbers each of four bits. It consists of eight inputs each for two four bit numbers and three outputs to generate less than, equal to and greater than between two binary numbers.
SKU: 1585 -
Analog, Discrete Electronic Components, ICs
74LS160 74160 74HC160 4-Bit Synchronous Decade Counter
The 74LS160 IC package, consisting of 16 pins, contains a single 4 bit synchronous counter circuit which can be wired for decade counting mod, without external logic chips. By wiring more than one 74LS160 together (cascading), it is possible to make higher count lengths (powers of ten). For example, two 74LS160s cascaded together would yield a counter capable of decimally counting the range 00 – 99.
SKU: 1584 -
Analog, Discrete Electronic Components, ICs
74LS90 7490 4-BIT Binary Decade BCD Counter IC
74LS90 Binary Counter Features
- It is used as a simple counter from 0 – 9.
- The IC has the ability to start from 0 and end at 9 automatically.
- IC can be used any TTL based device and microcontroller due to its TTL output.
- The IC has low power consumption.
- IC comes in multiple packages, PDSO, PDIP, and GDIP
- The IC has internal protection from clamp voltages.
SPECIFICATION
- The Power input range for IC is 4.75 to 5.25.
- The operating temperature range for IC is 0 to 70.
- The input voltages range for IC at HIGH state is 2.0 minimum and the LOW state is 0.7 maximum.
- IC draws output current at HIGH state is -0.4mA and for the LOW state is 8.0mA
- The internal clamp diode protection range is -1.5V.
More information is available in the datasheet:
SKU: 1582 -
Discrete Electronic Components, General ICs, ICs
74LS14 7414 Hex Schmitt Trigger Inverter Logic IC
Applications
- The IC can be used for Noise Removing.
- It has wide use in Power meter and Power analyzers.
You can download this Datasheet for 74LS14 Hex Inverter Schmitt Trigger from the link given below:
SKU: 1581 -
Discrete Electronic Components, ICs, Microcontrollers
Atmel 8051 AT89C51 AVR 40 Pin DIP Microcontroller
Discrete Electronic Components, ICs, MicrocontrollersAtmel 8051 AT89C51 AVR 40 Pin DIP Microcontroller
- Compatible with MCS-51 Products
- 4K Bytes of In-System Reprogrammable Flash Memory
- Endurance: 1,000 Write/Erase Cycles
- Fully Static Operation: 0 Hz to 24 MHz
- Three-Level Program Memory Lock
- 128 x 8-Bit Internal RAM
- 32 Programmable I/O Lines
- Two 16-Bit Timer/Counters
- Six Interrupt Sources
- Programmable Serial Channel
- Low Power Idle and Power Down Modes
SKU: 1451 -
Discrete Electronic Components, General ICs, ICs, Logic Gates
CD4073 CMOS Triple 3-Input AND Gate Breadboard-Friendly IC DIP-14
Discrete Electronic Components, General ICs, ICs, Logic GatesCD4073 CMOS Triple 3-Input AND Gate Breadboard-Friendly IC DIP-14
The CD4073BE is a 3-input CMOS Triple AND Gate provides the system designer with direct implementation of the AND function and supplement the existing family of CMOS gates.SKU: 1178 -
Discrete Electronic Components, General ICs, ICs
28BYJ-48 5V DC Mini Stepper Motor with ULN2003 DIP IC Stepper Motor Driver Module
Discrete Electronic Components, General ICs, ICs28BYJ-48 5V DC Mini Stepper Motor with ULN2003 DIP IC Stepper Motor Driver Module
This 5V DC 28BYJ-48 Stepper Motor is small, inexpensive and high-quality geared step motor. The 28BYJ-48 Stepper Motor and ULN2003 Stepper Motor Driver is a widely popular combination of the stepper motor and stepper driver, because of the stability and reliability of the system.
SKU: 0969 -
Discrete Electronic Components, ICs, Power Optimizer & Circuit Protection
0.5A 6V TO-252 SMD Voltage Regulator 78M06
Discrete Electronic Components, ICs, Power Optimizer & Circuit Protection0.5A 6V TO-252 SMD Voltage Regulator 78M06
Voltage regulators are very common in electronic circuits. They provide a constant output voltage for a varied input voltage. In our case the 78M06 IC is an iconic regulator IC that finds its application in most of the projects to regulate variable voltages to a fixed 6V output. This IC is the TO-252 case of 7806 IC to be used on SMD circuits.
SKU: 0884 -
Analog, Discrete Electronic Components, ICs
CD4049 Hex Inverter Buffer IC
CD4049 is a general purpose Hex Inverter Buffer IC. CD4049 holds six inverter gates on a single package. The IC works on the voltage range from 3V to 15V excessive voltage more than 15V will destroy the IC. So provide input voltage in the range of 3V to 15V. The IC invert the binary input i-e if we apply 1 at input it will out 0 and vice versa
SKU: 0886 -
Discrete Electronic Components, ICs, Logic Gates
CD4066 Quad Bilateral Switch – Multiplexer
The CD4066BE is a Quad Bilateral Switch IC, that is, it has four switches which can be controlled individual using a control pin. These switches can conduct in both the directions making it bilateral, it is commonly used for multiplexing analog or digital signals.
SKU: 0887 -
-
Discrete Electronic Components, General ICs, ICs
74LS37 7437 Quad 2-Input SN7437 NAND IC
- Logic IC Type: NAND GATE
- Load Capacitance (CL): 45.0 pF
- Operating Temperature-Min: 0.0 Cel
- Operating Temperature-Max: 70.0 Cel
- Power Supplies (V): 5
- Power Supply Current-Max (ICC): 54.0 mA
- Propagation Delay (tpd): 15.0 ns
- Schmitt Trigger: NO
- Supply Voltage-Nom (Vsup): 5
- Supply Voltage-Min (Vsup): 4.75 V
- Supply Voltage-Max (Vsup): 5.25 V
SKU: 0541 -
Discrete Electronic Components, General ICs, ICs
74LS17 7417 HEX Buffer HD7417 High Voltage Open Collector IC
Discrete Electronic Components, General ICs, ICs74LS17 7417 HEX Buffer HD7417 High Voltage Open Collector IC
- Convert TTL Voltage Levels to MOS Levels
- High Voltage Open Collector
- High Sink-Current Capability Design
- HEX Buffer
- Open-Collector Driver for Indicator Lamps
- Inputs Fully Compatible With Most TTL Circuits
SKU: 0569 -
Discrete Electronic Components, ICs, Logic Gates
74LS11 7411 Triple 3-Input AND Gate IC
- Logic Case Style: DIP
- Logic Type: AND
- No. of Inputs: 3
- No. of Pins: 14
- Operating Temperature Max: 70°C
- Operating Temperature Min: 0°C
- Output Current: 20mA
- Supply Voltage Max: 5.5V
- Supply Voltage Min: 4.5V
SKU: 0568 -
Discrete Electronic Components, General ICs, ICs
74LS05 7405 HEX Inverter SN7405 Open Collector IC
- IC, HEX INVERTER, 74HC05
- Logic Type: Inverter
- Output Current: 5.2mA
- No. of Inputs: 1
- Supply Voltage Min: 2V
- Supply Voltage Max: 6V
- Logic Case Style: DIP
- No. of Pins: 14
- Operating Temperature Min: -40°C
- Operating Temperature Max: 85°C
- Packaging: Each
- Base Number: 74
- IC Generic Number: 74HC05
- Logic Function Number: 7405
- Logic IC Base Number: 7405
- Logic IC Family: HC
- Logic IC Function: Hex Inverters with Open Drain Outputs
- MSL: MSL 1 – Unlimited
- Operating Temperature Range: -40°C to +85°C
- Output Current Max: 4mA
- SVHC: No SVHC (16-Dec-2013)
- Supply Voltage: 5V
- Supply Voltage Range: 2V to 6V
SKU: 0566 -
-
Discrete Electronic Components, ICs, Power Optimizer & Circuit Protection
LM723 Voltage Regulator IC
- Input supply voltage is up to 40v maximum
- Voltage output ranges from 3v to 37v
- Reference voltage is nearly 7v always
- Current from pin Vz is 25mA
- Current from pin Vref is 15mA
- Operating temperature range: -55°C to +150°C
- Line regulation of 0.01%Vout
- Load regulation of 0.03%Vout
- Ripple rejection of 74 dB
SKU: 0548 -
-
Discrete Electronic Components, General ICs, ICs
74HC192E 74LS192 4 Bit BCD Presettable Decade UP/DOWN Counter IC
Discrete Electronic Components, General ICs, ICs74HC192E 74LS192 4 Bit BCD Presettable Decade UP/DOWN Counter IC
Counter Type BCD/Decade Counter Counter Category Synchronous Counter Direction Bidirectional Supply Voltage 4.5 Package Type SOIC, PLASTIC, MS-012, SOIC-16 Logic Family CMOS, HC/UH Number of Pins 16 Number of Stages (Bits) 4 bits Clock Frequency 23 MHz Operating Temperature -55 to 125 C (-67 to 257 F) SKU: 0563 -
Discrete Electronic Components, General ICs, ICs
74LS95 4-BIT SHIFT REGISTER / PARALLEL IN AND SERIAL OUT
Discrete Electronic Components, General ICs, ICs74LS95 4-BIT SHIFT REGISTER / PARALLEL IN AND SERIAL OUT
- Product Category: Counter Shift Registers
- Counting Sequence: Serial/Parallel to Parallel
- Number of Circuits: 1
- Number of Bits: 4 bit
- Package/Case: PDIP-14
- Logic Family: LS
- Logic Type: Bipolar
- Number of Input Lines: 5
- Propagation Delay Time: 32 ns
- Supply Voltage – Max: 5.25 V
- Minimum Operating Temperature: 0 °C
- Maximum Operating Temperature: + 70 °C
- Function: Shift Register
- Series: SN74LS95B
- Mounting Style: DIP
- Number of Output Lines: 4
- Product Type: Counter Shift Registers
- Subcategory: Logic ICs
- Unit Weight: 1 g
SKU: 0564 -
Discrete Electronic Components, Encoder & Decoder ICs, ICs
PT2272 L4 RF REMOTE DECODER DIP-18 IC
- Family: CMOS
- Case: DIP-18 | SOP-20;
- Input Voltage: Vcc: 4-15 VDC;
- Icc: <1 µA (Stand-by)
- Pd: __ mW
- Operational Temperature: -40…+85 °C
- Data Bits: 4
- Max. Outputs: 4
- Output Type: Digital / Binary
- Commonly used for RF and IR wireless transmission
- Available in 16-pin DIP, 20-pin SOP
SKU: 563 -
Discrete Electronic Components, Encoder & Decoder ICs, ICs
74HC164 8bit Serial-In / Parallel-Out Shift Register
Discrete Electronic Components, Encoder & Decoder ICs, ICs74HC164 8bit Serial-In / Parallel-Out Shift Register
- 8-bit Gated Serial Inputs with Asynchronous Clear
- Clocking Occurs on the Low-to-High Transition of the Clock Input
- Data at the Serial Inputs can be Changed on High or Low State of the Clock
- Standard TTL Switching Voltages
- Superseded, Not Recommended for New Designs
- Typical operating frequency: 50 MHz
- Typical propagation delay: 19 ns (clock to Q)
- Wide operating supply voltage range: 2V to 6V
- Low input current: 1 µA maximum
- Low quiescent supply current: 80 µA maximum
- Fanout of 10 LS-TTL loads
- Package type: DIP
- No. of pins: 14
SKU: 0565 -
Analog, Discrete Electronic Components, ICs
CD4033 CMOS Decade Counter Divider IC
- Logic Family / Base Number: CD4033
- Counter Type: Decade / Divider
- Clock Frequency: 16MHz
- Count Maximum: 10 Logic
- Case Style: DIP
No. of Pins: 16Pins - Supply Voltage Min: 3V
- Supply Voltage Max: 18V
- Logic IC Family: CD4000
- Logic IC Base Number: 4033
- Operating Temperature Min: -55°C
- Operating Temperature Max: 125°C
- Product Range: CD4000 LOGIC Series
SKU: 0411 -
Analog, Discrete Electronic Components, ICs
CD4017 Decade Counter Divider IC with 10 Decoded Outputs
- The supply voltage of this IC is 3V to 15V.
- It is compatible with TTL (Transistor-Transistor Logic).
- The clock speed or operational speed of CD4017 IC is 5 MHz
- 5-stage Divide-by-10 Johnson Counter with 10 Decoded Outputs and a Carry Bit
- Medium Speed up to 5MHz
- Operating Temperature to 85°C.
SKU: 0412 -
Discrete Electronic Components, General ICs, ICs
3 to 8 line Decoder / Demultiplexer 74HC138
• Logic Type: decoder / demultiplexer
• No. output channels: 8
• Supply Voltage Range: 2V to 6V
• Package Type: DIP
• Pin number: 16
• Operating temperature range: -55 ° C to +125 ° C
• SVHC: No SVHC
• Device label: 74
• Device Marking: HD74HC138P
• Package Type: DIP
• Operating Temperature Min: -55 ° C
• highest working temperature: 125 ° C
• Supply Voltage: 6V
• Supply voltage: 6V
• The minimum supply voltage: 2V
• chip label: 74HC138
• Surface Mount Devices: through-hole mounting
• Output Current: 5.2mA
• logic chip function: Logic 4-to-16 Line Decoder / Demultiplexer
• logic chip series: HCSKU: 0413
