7 Inch HMI LCD Display Touch Panel with Shell DMG80480C070_15WTR (Commercial grade)
The 7 inch HMI LCD Resistive Touch Display with Shell is a Seamless Human Machine Interface (HMI) display module solution that provides a control and visualization interface for any Raspberry Pi and Arduino kits.
Availability:
In stock
₨ 17,000
In stock
DWIN 7 Inch HMI LCD Display with Shell Resistive Touch Panel DMG80480C070_15WTR (Commercial grade) LCD Screen
Features:
- 800*480 resolution, 262K colors, TN-TFT-LCD;
- Resistive touch screen;
- RS232 and RS485 Interface, 8Pin3.81mm Socket connection wire;
- Download via SD card or on-line serial port;
- 8MBytes NOR Flash, for fonts, pictures and audio files;
- Brightness is up to 200nit;
- TN View Angle: 70/70/50/70 (L/R/U/D) ;
Package Includes:
1 x 7 inch HMI display screen with shell
| Color | 262K colors |
| LCD Type | TN, TFT LCD |
| Viewing Angle | Normal viewing angle, 70°/70°/50°/70°（L/R/U/D） |
| Display Area（A.A） | 154.1mm (W) ×85.9mm (H) |
| Resolution | 800×480 |
| Backlight | LED |
| Brightness | 200nit |
| Type | RTP (Resistive touch panel) |
| Structure | ITO film + ITO glass |
| Touch Mode | Support point touch and drag |
| Surface Hardness | 3H |
| Light Transmittance | Over 80% |
| Life | Over 1,000,000 times touch |
| Power Voltage | 6~36V |
| Operation Current | VCC = 12V, Max backlight,280mA |
| VCC = 12V, Backlight off,140mA |
