SMA Female Coax RF Straight Cable PCB Connector Jack Goldplated
Compare Availability:
In stock
₨ 130
In stock
Features:
- SMA female for 1.6mm thick solder edge PCB mount straight RF connector
- Gold plated PCB SMA Female Coaxial Connector
- Temp.range: -65～ +165 (PE Cable -～ +85)
- Vibration: MIL-STD-202,Method 213
- Impedance: 50Ω
- Working Voltage: 335V max
- Withstand?Voltage: 1000V rms
- Contact?resistance:Center?Contact≤3mΩ
- Outer?Contact≤2mΩ
- Insulation?resistance:≥5000?mΩ
- Insertion?loss: ≥0.15 dB/6GHz
- VSWR?Straight: ≤1.10+0.002f
- ≤1.05+0.001f
- Right?angle:≤1.20+0.00
- ≤1.10+0.001f
- Durability(mating): ≥ 500 (cycles)
