JK Smart BMS LFP Li-ion 8S-24S 60A BMS Battery Management System for Li-ion Lifepo4 Battery Pack Balanced Charging Board LiFePO4 Lithium Battery Pack

The JK Smart BMS 60A with 0.6A Active Balancer refers to a series of high-performance battery management systems designed for LiFePO4, Li-ion, and LTO battery packs. These units are distinguished by their active equalization technology, which transfers energy between cells to balance voltage differences rather than wasting it as heat.

Features:

• [Built-in BT] No need extra BT interface, all types of JK BMS have built-in BT
• [App Download] Scan the QR code on jk-bms to download the app
• [APP Login] The login password is 1234 and the authorization password is 123456.
• [Active Balance] All types of JK BMS are actively balanced
• [Automatic Identification] It can automatically identify battery properties and supports ternary lithium batteries, lithium iron phosphate batteries and lithium titanate batteries.
• [One Key Setting] You can set the parameters with one key on the APP
• [Overshoot Protection] When the voltage is higher than the set condition, the charging will be automatically stopped to protect the battery
• [Over-discharge protection] When the voltage is lower than the set condition, the discharge is automatically stopped to protect the battery
• [Enhanced Safety] Safeguard your battery with protection against overcharging, over-discharging, overcurrent, short circuits, and temperature extremes. JKBMS Active Equalization extends battery life and enhances performance
• [Wide Application] This versatile BMS works with Li-ion, LiFePO4, and LTO batteries. Suitable for Electric Sightseeing Car, Micro EV, and Electric Cargo Tricycle and so on, it offers seamless integration and top performance

Core Specifications:

• Continuous Current: 60A charge/discharge.
• Active Balancing: 0.6A balancing current (adjustable from 0.1A to 0.6A via app).
• Connectivity: Built-in Bluetooth for real-time monitoring and configuration via the JK BMS mobile app.
• Communication Interfaces: Standard support for RS485 and CAN (on specific versions).
• Safety Protections: Comprehensive protection against over-charge, over-discharge, over-current, short circuits, and low-temperature charging.
• Accuracy: Voltage acquisition accuracy within ±5mv

Packing List:

• Smart BMS (JK-BD6A24S6P) * 1,
• Wires (70cm) * 1,
• Switch (50cm) * 1,
• NTC (40cm) * 1,
• Operate manual * 1
