Optical Endstop Optical Limit Switch for 3D Printers RAMPS 1.4

The optical endstop is a reliable endstop / switch solution for any type of 3D printers and other CNC and/ or 3D tools. This fully assembled plug and play Optical (Opto) Endstop Light Control Limit Switch is very suitable for your 3D printing or CNC project. The Optical Endstop Switch will immediately output the digital control when the light is blocked and turn the LED on.

Compatible with RAMPS 1.4 board

Features:

• High Precision: Offers better accuracy than mechanical switches due to optical sensing.
• Durability: No physical contact means longer life, capable of >100,000 cycles.
• LED Indicator: Built-in LED lights up when the sensor is triggered.
• Plug-and-Play: Designed for easy integration with RAMPS 1.4, RepRap, and other CNC machines.
• Low Noise: Operates quietly, improving the overall printing experience.

Specifications:

• Operating Voltage: 5V DC
• Sensor Model: TCST210 (Photo-interrupter)
• Cable Length: Typically 50cm to 1m
• Dimensions: Approximately 33.02mm x 10mm
• Output Type: Digital Signal
• Compatibility: RAMPS 1.4, Sanguinololu 1.3a, and other 3D printer controller boards.

Installation Tips:

• Wiring: The board usually uses three pins: VCC (5V), GND, and Signal.
• Connection: Connect to the X-Min/Max, Y-Min/Max, or Z-Min/Max pins on the RAMPS board.
• Firmware: No major firmware changes are usually needed, but, sometimes a pull-up resistor must be enabled in the firmware if it uses an open-collector output.
