RS485 to TTL UART Converter Module
RS485 to TTL / TTL to RS485 converter is a module that allows the TTL interface of the microcontroller to be transferred to the RS485 module / MAX485 module. It is generally used for industrial automation. This module adds lightning protection design and anti-jamming design. When we use it in the field and carry out long distance transmission, we can Connect the GND end of the module to the ground so that lightning protection and anti-interference can be achieved. This Max485 to TTL module is online in Pakistan at electrobes.
In stock
₨ 100
In stock
Key Features & Benefits
- MAX485 Driver/Receiver
Industry-standard chipset ensures dependable RS-485 signalling, low power draw, and extended service life. - Extended Range & Multi-Drop
Communicate reliably over twisted-pair cabling up to 1,200 m and connect up to 32 nodes per bus. - High Data Throughput
Supports up to 20 Mbps for real-time control, telemetry, and high-speed data logging. - Robust Noise Immunity
Differential signaling and integrated fail-safe resistors maintain data integrity in electrically noisy environments. - Automatic Direction Control
Built-in DE/RE auto-toggle simplifies half-duplex operation no external code needed to manage line direction. - Wide Voltage Compatibility
Operates from 3.3 V to 5 V logic, making it plug-and-play with popular development boards. - Compact PCB Footprint
Measures just 30 × 20 mm ideal for tight enclosures and crowded control panels.
Technical Specifications
| Parameter | Specification |
|---|---|
| Chipset | MAX485E (driver/receiver pair) |
| Bus Standard | ANSI-TIA/EIA-485 (RS-485) |
| Data Rate | Up to 20 Mbps |
| Bus Distance | Up to 1,200 m on 24-AWG cable |
| Node Capacity | 32 transceivers per bus |
| Supply Voltage | 3.3–5 V DC |
| Logic Levels | 3.3 V / 5 V TTL-compatible |
| Direction Control | Automatic DE/RE toggling |
| Protection | Fail-safe resistors & thermal shutdown |
| Dimensions | 30 × 20 × 8 mm |
| Operating Temp. | –40 °C to +85 °C |
Ideal Applications
| Application | Benefit |
|---|---|
| Industrial Automation | Control PLCs, drives, and sensors across factory floors |
| Building Management | Link HVAC, lighting, and security systems over one trunk |
| Remote Monitoring | Transmit sensor data from distant or harsh locales |
| IoT & Embedded Networks | Coordinate Multiple MCUs for distributed sensing |
| Smart Grid & Energy | Interface smart meters and substation equipment |
| Process Control | Ensure precise command and feedback loops |
What’s Included
- 1 × RS-485 Communication Module (MAX485 chipset)
- 3.3V perfectly compatible with 5.0V power supply
- 3.3V and 5.0V signal perfectly compatible
- Working temperature range: -40 ℃ to + 85 ℃
- Transmission distance up to kilometers (with 850 meters of 2 * 1.5 cable to do the test, it is recommended to use in the 800 meters, more than 800 meters, please add repeaters)
- Semi-hole process design, the thickness of 0.8mm, makes it easy to use as a combo board, it can also be welded terminal use
- Has RXD, TXD signal lights to observe send and receive status
